Quick and Easy Installation

RESISTANT TO WEAR.

Cigarette Fire Resistant

Not affected by stains

Scratch Resistant

Easy to Clean

Resistant to Point Impacts

UV-Resistant




      FEATURES
      ZEN BASE
      ZEN
      RELATED STANDARD




      Width
      mm
      193
      193
      TS EN 13329


      Length
      mm
      1200
      1200
      TS EN 13329


      Thickness
      mm
      8
      8
      TS EN 13329


      Weight
      kg
      13,8
      13,8
      TS EN 323


      Thickness Difference Between Elements
      mm
      Tort <0,50   tmax-tmin <0,50
      TS EN 13329


      Abrasion Resistance
      Revolutions
      Revolutions>2000
      Revolutions>4000
      TS EN 13329


      Surface Soundness
      N/mm²
      AC3 ≥1
      AC4 ≥1,25
      TS EN 13329


      Impact Resistance
      N

        Class 23–31: IC1 •
        Class 32: IC2 •
        Class 33: IC3

      TS EN 13329


      Squareness Deviation
      mm
      Qmax <0,2
      TS EN 13329


      Length Tolerance
      mm
      l<1500 difference <0,5
      TS EN 13329


      Width Tolerance
      mm
      Average width difference 0,10 – wmax-wmin <0,20
      TS EN 13329


      Straightness Deviation / Bowing
      mm
      0,30
      TS EN 13329


      Surface Flatness
      mm

        Fw concave <%0,15

        Fw convex <%0,20

        Fl concave <%0,50

        Fl convex <%1,00

      TS EN 13329


      Joint Opening
      mm
      O average <0,15 – O max 0,15
      TS EN 13329



      Joint Height Difference
      mm
      H average <0,10   Hmax <0,15
      TS EN 13329



      Scratch Resistance
      N
      >3,5
      TS EN 438-2+A1



      Castor Chair Effect
      Revolutions
      There shall be no change or damage in appearance
      TS EN ISO 4918



      Furniture Leg Effect
      Revolutions
      There shall be no visible damage
      TS EN ISO 16581



      Resistance to Hot Objects
      Class
      Class 4
      TS EN 13329



      Resistance to Water Vapor
      Class
      Class 4
      TS EN 13329



      Resistance to Staining
      Class
      Class 5
      TS EN 13329



      24-Hour Thickness Swelling in Water
      %
      <%18
      TS EN 13329



      Bending Strength
      N/mm²
      40
      TS EN 317



      Modulus of Elasticity
      N/mm²
      3500
      TS EN 310



      Tensile Strength
      N/mm²
      ≥1,2
      TS EN 319

FEATURES	ZEN BASE	ZEN	RELATED STANDARD
Width	mm	193	193	TS EN 13329
Length	mm	1200	1200	TS EN 13329
Thickness	mm	8	8	TS EN 13329
Weight	kg	13,8	13,8	TS EN 323
Thickness Difference Between Elements	mm	Tort <0,50 tmax-tmin <0,50	TS EN 13329
Abrasion Resistance	Revolutions	Revolutions>2000	Revolutions>4000	TS EN 13329
Surface Soundness	N/mm²	AC3 ≥1	AC4 ≥1,25	TS EN 13329
Impact Resistance	N	Class 23–31: IC1 • Class 32: IC2 • Class 33: IC3	TS EN 13329
Squareness Deviation	mm	Qmax <0,2	TS EN 13329
Length Tolerance	mm	l<1500 difference <0,5	TS EN 13329
Width Tolerance	mm	Average width difference 0,10 – wmax-wmin <0,20	TS EN 13329
Straightness Deviation / Bowing	mm	0,30	TS EN 13329
Surface Flatness	mm	Fw concave <%0,15 Fw convex <%0,20 Fl concave <%0,50 Fl convex <%1,00	TS EN 13329
Joint Opening	mm	O average <0,15 – O max 0,15	TS EN 13329
Joint Height Difference	mm	H average <0,10 Hmax <0,15	TS EN 13329
Scratch Resistance	N	>3,5	TS EN 438-2+A1
Castor Chair Effect	Revolutions	There shall be no change or damage in appearance	TS EN ISO 4918
Furniture Leg Effect	Revolutions	There shall be no visible damage	TS EN ISO 16581
Resistance to Hot Objects	Class	Class 4	TS EN 13329
Resistance to Water Vapor	Class	Class 4	TS EN 13329
Resistance to Staining	Class	Class 5	TS EN 13329
24-Hour Thickness Swelling in Water	%	<%18	TS EN 13329
Bending Strength	N/mm²	40	TS EN 317
Modulus of Elasticity	N/mm²	3500	TS EN 310
Tensile Strength	N/mm²	≥1,2	TS EN 319
