UV-Resistant

Scratch Resistant

Quick and Easy Installation

Not affected by stains

Easy to Clean

Cigarette Fire Resistant

RESISTANT TO WEAR.

Resistant to Point Impacts




      FEATURES
      ZEN BASE
      ZEN
      RELATED STANDARD




      Width
      mm
      193
      193
      TS EN 13329



      Length
      mm
      1200
      1200
      TS EN 13329



      Thickness
      mm
      8
      8
      TS EN 13329



      Weight
      kg
      13,8
      13,8
      TS EN 323



      Thickness Difference Between Elements
      mm
      Tort <0,50   tmax-tmin <0,50
      TS EN 13329



      Abrasion Resistance
      Cycles
      Cycles>2000
      Cycles>4000
      TS EN 13329



      Surface Strength
      N/mm²
      AC3 ≥1
      AC4 ≥1,25
      TS EN 13329



      Impact Resistance
      N

        Class 23–31: IC1 •
        Class 32: IC2 •
        Class 33: IC3

      TS EN 13329



      Squareness Deviation
      mm
      Qmax <0,2
      TS EN 13329



      Length Tolerance
      mm
      l<1500 difference <0,5
      TS EN 13329



      Width Tolerance
      mm
      Waverage difference 0,10 – wmax-wmin <0,20
      TS EN 13329



      Warping
      mm
      0,30
      TS EN 13329



      Surface Flatness
      mm

        Fw concave <%0,15

        Fw convex <%0,20

        Fl concave <%0,50

        Fl convex <%1,00

      TS EN 13329



      Joint Opening
      mm
      O average <0,15 – O max 0,15
      TS EN 13329



      Joint Height Difference
      mm
      Haverage <0,10   Hmax <0,15
      TS EN 13329



      Scratch Resistance
      N
      >3,5
      TS EN 438-2+A1



      Caster Chair Effect
      Cycles
      There shall be no visible change or damage in appearance
      TS EN ISO 4918



      Furniture Leg Effect
      Cycles
      There should be no visible damage
      TS EN ISO 16581



      Resistance to Hot Objects
      Class
      Class 4
      TS EN 13329



      Resistance to Water Vapor
      Class
      Class 4
      TS EN 13329



      Stain Resistance
      Class
      Class 5
      TS EN 13329



      24-Hour Water Swelling
      %
      <%18
      TS EN 13329



      Bending Strength
      N/mm²
      40
      TS EN 317



      Modulus of Elasticity
      N/mm²
      3500
      TS EN 310



      Tensile Strength
      N/mm²
      ≥1,2
      TS EN 319

FEATURES	ZEN BASE	ZEN	RELATED STANDARD
Width	mm	193	193	TS EN 13329
Length	mm	1200	1200	TS EN 13329
Thickness	mm	8	8	TS EN 13329
Weight	kg	13,8	13,8	TS EN 323
Thickness Difference Between Elements	mm	Tort <0,50 tmax-tmin <0,50	TS EN 13329
Abrasion Resistance	Cycles	Cycles>2000	Cycles>4000	TS EN 13329
Surface Strength	N/mm²	AC3 ≥1	AC4 ≥1,25	TS EN 13329
Impact Resistance	N	Class 23–31: IC1 • Class 32: IC2 • Class 33: IC3	TS EN 13329
Squareness Deviation	mm	Qmax <0,2	TS EN 13329
Length Tolerance	mm	l<1500 difference <0,5	TS EN 13329
Width Tolerance	mm	Waverage difference 0,10 – wmax-wmin <0,20	TS EN 13329
Warping	mm	0,30	TS EN 13329
Surface Flatness	mm	Fw concave <%0,15 Fw convex <%0,20 Fl concave <%0,50 Fl convex <%1,00	TS EN 13329
Joint Opening	mm	O average <0,15 – O max 0,15	TS EN 13329
Joint Height Difference	mm	Haverage <0,10 Hmax <0,15	TS EN 13329
Scratch Resistance	N	>3,5	TS EN 438-2+A1
Caster Chair Effect	Cycles	There shall be no visible change or damage in appearance	TS EN ISO 4918
Furniture Leg Effect	Cycles	There should be no visible damage	TS EN ISO 16581
Resistance to Hot Objects	Class	Class 4	TS EN 13329
Resistance to Water Vapor	Class	Class 4	TS EN 13329
Stain Resistance	Class	Class 5	TS EN 13329
24-Hour Water Swelling	%	<%18	TS EN 13329
Bending Strength	N/mm²	40	TS EN 317
Modulus of Elasticity	N/mm²	3500	TS EN 310
Tensile Strength	N/mm²	≥1,2	TS EN 319
